The Autonics BR Series is a highly popular line of Ø18mm cylindrical photoelectric sensors celebrated for its long-distance detection capacities and rugged design. Equipped with specialized digital signal processing (DSP), the BR series delivers superior noise immunity against electrical and magnetic interference. This makes it a standard component choice for high-speed conveyor sorting lines, automated storage systems, and industrial packaging machinery
✓ 100% Genuine▣ GST Invoice⚙ Technical Support🔒 Secure Payment
Non-returnable
Select a model to confirm price and availability.
Model
🚚 Delivery / lead time confirmed before dispatch🧾 GST invoice provided⚙ Engineering selection support available
Product Details
Ratings & Reviews
Product Details
Product Details
Key Specifications (Standard Base Profile)
| Feature | Detail |
|---|---|
| Manufacturer Series | Autonics BR Series (Cylindrical Type) |
| Barrel Diameter Size | Standard M18 x 1 Threaded Barrel |
| Housing Construction | Nickel-Plated Brass or Black Polyamide Plastic |
| Operating Voltage | 12 to 24 VDC (Accepts functional window of 10-30 VDC) |
| Output Load Current | Maximum 200 mA |
| Switch Latency / Time | Max. 1 ms response cycle latency |
| Optical Beam Source | Infrared LED (850 nm wavelength) |
| Operation Logic Mode | Selectable Light-ON or Dark-ON via control wire |
| Enclosure Ingress Sealing | IEC Standard IP66 protection rating |
| Cable / Termination | Pre-wired 2-metre 4-core PVC connection line |
